My HID classes are now in version 1.0 and I’m not going to change them again without good reason. The change is that the call back action passes the changed element back as the first parameter, followed by all the other parameters. It’s redundant, but it matches how the subclasses work. This should be usable for HID applications. a helpfile will be forthcoming.
I am trying to write a Biquad filter UGen and also to compile a FFTW UGen that my friend wrote. Jam fails when I try to compile, on both files. I think there is a step missing in the howto document on Ugen writing. My code is simple and the syntax looks ok. I’ve done every step (as far as I know) in the howto. bah. I could use a better error message than “jam failed.” sheesh. I like XCode, but it’s got nothing on the Boreland compilers I used to use back in the 90’s as far as usability and usefulness of error messages.
Workaround: Take an existing target and duplicate it and use that for your target. Rename it and replace the files in it with your own. Ctrl-click on the target to bring up a menu with the option to duplicate.
Tags: Celesteh, SuperCollider

Download a new version of my HID classes.
So I think some of my original features were overzealous, so some of them have been removed. For instance, no more specifying a ControlSpec for an HIDElementExt. If you want to use a ControlSpec, you should attach the HIDElementExt (or HIDElement Group) to a CV by means of the action. Remember that CVs are really useful objects. See their help file for more information. For example of how to attach one:

element.action_({arg vendorID, productID, locID, cookie, value;

 var scaled, mycv;

 scaled = element.scale(value);

 mycv = cvDictionary.at(element.usage.asSymbol);
 mycv.input_(scaled);
});

Note the name and order of arguments, as this is a change. In this example, cvDictionary is an IdentityDictionary where CVs are stored according to the element.usage as a key. scale is a message you can pass to an element in which a value is scaled according to the min and max to be a number between 0 and 1. You can still set the min and max of an element based on what you’ve discovered to be the range of your HID, regardless of what lies the device may whisper in your ear about it’s ranges.
The HIDDeviceExt.configure message was not really needed, so it’s gone.
Here is some code to automatically generate a GUI for every HID that you have attached. Note that you will need the Conductor class for it, which is part of the Wesleyan nightly build. This GUI will give you one line for every reported piece of the device. You can then try moving everything around to see what their actual ranges are (if they are smaller than reported) and the correlation between reported names and the elements.

(

 var elems, names, cv, conductor;

 HIDDeviceServiceExt.buildDeviceList;

 HIDDeviceServiceExt.devices.do({ arg dev;

  elems = [];
  names = [];

  dev.queueDevice;

  dev.elements.do ({ arg elm;

   cv = CV.new.sp(0, elm.min, elm.max, 0, 'linear');
   elems = elems.add(cv);
   names = names.add(elm.usage.asSymbol);
   elm.action_({ arg vendorID, productID, locID, cookie, value;

    var scaled, mycv;

    scaled = elm.scale(value);

    mycv = conductor.at(elm.usage.asSymbol);
    mycv.input_(scaled);
   });

  });

  conductor = Conductor.make({ arg cond;

   elems.do({ arg item, index;

    cond.put(names[index], item);
   });

   cond.argList = cond.argList ++ elems;
   cond.argNames = cond.argNames ++ names;
   cond.valueItems = cond.valueItems ++ names;
   cond.guiItems = cond.valueItems;
  });

  conductor.show;

 });

 HIDDeviceServiceExt.runEventLoop;

)

Then stop it with:

HIDDeviceServiceExt.stopEventLoop;

But what if the returned values are outside of the range? And what are the cookies? You should then generate a little report to correlate everything.

(
 HIDDeviceServiceExt.devices.do({arg dev;
  [dev.manufacturer, dev.product, dev.vendorID, dev.productID, dev.locID].postln;
  dev.elements.do({arg ele;
   [ele.type, ele.usage, ele.cookie, ele.min, ele.max, ele.minFound, ele.maxFound].postln;
  });
 });
)

You can use the minFound and maxFound data to calibrate the device.
This is my current code to configure my (crappy) joystick:

HIDDeviceServiceExt.buildDeviceList;
HIDDeviceServiceExt.queueDeviceByName('USB Joystick STD');

(

 var thisHID, simpleButtons, buttons, stick;

 thisHID = HIDDeviceServiceExt.deviceDict.at('USB Joystick STD');
 simpleButtons = HIDElementGroup.new;
 buttons = HIDElementGroup.new;
 stick = HIDElementGroup.new;

 thisHID.deviceSpec = IdentityDictionary[
   // buttons
   trig->7, left->9, right->10, down->8, hat->11,
   // stick
   x->12, y->13,
   wheel->14,
   throttle->15
  ];


 simpleButtons.add(thisHID.get(trig));
 simpleButtons.add(thisHID.get(left));
 simpleButtons.add(thisHID.get(right));
 simpleButtons.add(thisHID.get(down));

 buttons.add(simpleButtons);
 buttons.add(thisHID.get(hat));

 stick.add(thisHID.get(x));
 stick.add(thisHID.get(y));

 // make sure each element is only lsted once in the nodes list, or else it
 // will run it's action once for each time a value arrives for it

 thisHID.nodes = [ buttons, stick, thisHID.get(wheel), thisHID.get(throttle)];

 // When I was testing my joystick, I noticed that it lied a bit about ranges

 thisHID.get(hat).min = -1;  // it gives back -12 for center, but -1 is close enough

 // none of the analog inputs ever went below 60


 thisHID.get(wheel).min = 60;
 thisHID.get(throttle).min = 60;
 // can set all stick elements at once
 stick.min = 60;
)

Setting the min and the max for each element is used for the scale message. If you don’t want to bother scaling the values to be between 0 and 1 (or some other range) and you set the threshold to 0, then you can skip setting the min and the max.
Here is a silly example of using the x and y axis of my joystick to control the frequency and amplitude of a Pbind in a GUI. Note that it would work almost identically without the GUI.

(

 HIDDeviceServiceExt.runEventLoop;

 Conductor.make({arg cond, freq, amp;

  var joystick;

  freq.spec_(freq);
  amp.spec_(amp);

  joystick = HIDDeviceServiceExt.deviceDict.at('USB Joystick STD');

  joystick.get(y).action_({ arg vendorID, productID, locID, cookie, value;

   freq.input_(joystick.get(y).scale(value));
  });

  joystick.get(x).action_({ arg vendorID, productID, locID, cookie, value;

   amp.input_(joystick.get(x).scale(value));
  });

  cond.name_("silly demo");

  cond.pattern_( Pbind (

   freq, freq,
   amp, amp
  ));

 }).show;

)

Don’t forget to stop the loop when you’re done:

HIDDeviceServiceExt.stopEventLoop;

As you may have guessed from this EventLoop business, HIDs are polled. Their timing, therefore, may not be as fast as you’d like for gaming. They may be more suited to controlling Pbinds like in the silly example, rather than Synth objects. You will need to experiment on your own system to see what will work for you.
The HIDElementExt all have a threshold of change below which they will not call their actions. This defaults to 5%, which is a good value for my very crappy joystick. You can set your own threshold. It’s a floating point number representing a percent change, so you can put it between 0 and 1. Again, you may want to experiment with this. Most HIDs have a little bit of noise and flutter where they report tiny actions where none occurred. Also, do not buy a 5€ joystick from a sketchy shop. It’s range will suck and it will will flutter like crazy and it will be slow and you will end up buying a more expensive joystick anyway.

joystick.threshold_(0.01); // 1%

Tags: SuperCollider, HID, Celesteh

So, game controllers and joysticks and the like are called Human Interface Devices (HID). There is some HID stuff built into SuperCollider, but it seemed sort of half implemented. They let you specify things, but not do much with it. So I wrote an extension yesterday, which maybe I should submit as something official or a replacement, although I didn’t bother checking first if anybody else had already done anything. No internet access at home sucks.

To use it, download HID.sc and put it in ~/Library/Application Support/SuperCollider/Extensions. Plug in your joystick or controller. Start SuperCollider.
First, you want to know some specifications for your device, so execute:

HIDDeviceServiceExt.buildDeviceList;


(
HIDDeviceServiceExt.devices.do({arg dev;
  [dev.manufacturer, dev.product, dev.vendorID, dev.productID, dev.locID].postln;
  dev.elements.do({arg ele;
   [ele.type, ele.usage, ele.cookie, ele.min, ele.max].postln;
  });
});
)

I got back:

  [ , USB Joystick STD, 1539, 26742, 454033408 ]
  [ Collection, Joystick, 1, 0, 0 ]
  [ Collection, Pointer, 2, 0, 0 ]
  [ Button Input, Button #5, 3, 0, 1 ]
  [ Button Input, Button #6, 4, 0, 1 ]
  [ Button Input, Button #7, 5, 0, 1 ]
  [ Button Input, Button #8, 6, 0, 1 ]
  [ Button Input, Button #1, 7, 0, 1 ]
  [ Button Input, Button #2, 8, 0, 1 ]
  [ Button Input, Button #3, 9, 0, 1 ]
  [ Button Input, Button #4, 10, 0, 1 ]
  [ Miscellaneous Input, Hatswitch, 11, 0, 3 ]
  [ Miscellaneous Input, X-Axis, 12, 0, 127 ]
  [ Miscellaneous Input, Y-Axis, 13, 0, 127 ]
  [ Miscellaneous Input, Z-Rotation, 14, 0, 127 ]
  [ Miscellaneous Input, Slider, 15, 0, 127 ]
  [ a HIDDevice ]

Ok, so I know the name of the device and something about all the buttons and ranges it claims to have. (Some of them are lies!) So, I want to assign it to a variable. I use the name.

j = HIDDeviceServiceExt.deviceDict.at('USB Joystick STD');

Ok, I can set the action for the whole joystick to tell me what it’s doing, or I can use the cookie to set the action for each individual element. I want to print the results. In either case, the action would look like:

x.action = { arg value, cookie, vendorID, productID, locID, val;
 [ value, cookie, vendorID, productID, locID, val].postln;
};

You need to queue the device and start the polling loop before the action will execute.

HIDDeviceServiceExt.queueDeviceByName('USB Joystick STD');
HIDDeviceServiceExt.runEventLoop;

It will start printing a bunch of stuff as you move the controls. When you want it to stop, you can stop the loop.

 HIDDeviceServiceExt.stopEventLoop;

Ok, so what is all that data. The first is the output of the device scaled to be between 0-1 according to the min and max range it reported by the specification. The next is very important. It’s the cookie. The cookie is the ID number for each element. You can use that to figure out which button and widget is which. Once you know this information, you can come up with an IdentityDictionary to refer to every element by a name that you want. Mine looks like:

  j.deviceSpec = IdentityDictionary[
   // buttons
   a->7, left->9, right->10, down->8, hat->11,
   // stick
   x->12, y->13,
   wheel->14,
   throttle->15
  ];

The last argument in our action function was the raw data actually produced by the device. You can use all your printed data to figure out actual ranges of highs and lows, or you can set the action to an empty function and then restart the loop. Push each control as far in every direction that it will go. Then stop the loop. Each element will recall the minimum and maximum numbers actually recorded.

(
j.elements.do({arg ele;
   [ele.type, ele.usage, ele.cookie, ele.min, ele.max, ele.minFound, ele.maxFound].postln;
  });
)

This gives us back a table like the one we saw earlier but with two more numbers, the actual min and the actual max. This should improve scaling quite a bit, if you set the elements min and max to those values.   ele.min = ele.minFound;   Speaking of scaling, there are times when you want non-linear or within a different range, so you can set a ControlSpec for every element. Using my identity dictionary:

j.get(throttle).spec = ControlSpec(-1, 1, step: 0, default: 0);

Every element can have an action, as can the device as a whole and the HIDService as a whole. You can also create HIDElementGroup ‘s which contain one or more elements and have an action. For example, you could have an action specific for buttons. (Note that if you have an action for an individual button, one for a button group and one for the device, three actions will be evaluated when push the button.) Currently, an element can only belong to one group, although that might change if somebody gives me a good reason.
This is a lot of stuff to configure, so luckily HIDDeviceExt has a config method that looks a lot like make in the conductor class. HIDDeviceExt.config takes a function as an argument. The function you write has as many arguments as you want. The first refers to the HIDDeviceExt that you are configuring. The subsequent ones refer to HIDElementGroup ‘s. The HIDDeviceExt will create the groups for you and you can manipulate them in your function. You can also set min and max ranges for an entire group and apply a ControlSpec to an entire group. My config is below.

 j.config ({arg thisHID, simpleButtons, buttons, stick;

  thisHID.deviceSpec = IdentityDictionary[
   // buttons
   a->7, left->9, right->10, down->8, hat->11,
   // stick
   x->12, y->13,
   wheel->14,
   throttle->15
  ];


  simpleButtons.add(thisHID.get(a));
  simpleButtons.add(thisHID.get(left));
  simpleButtons.add(thisHID.get(right));
  simpleButtons.add(thisHID.get(down));

  buttons.add(simpleButtons);
  buttons.add(thisHID.get(hat));

  stick.add(thisHID.get(x));
  stick.add(thisHID.get(y));

  // make sure each element is only lsted once in the nodes list, or else it
  // will run it's action once for each time a value arrives for it

  thisHID.nodes = [ buttons, stick, thisHID.get(wheel), thisHID.get(throttle)];

  // When I was testing my joystick, I noticed that it lied a bit about ranges

  thisHID.get(hat).min = -1;  // it gives back -12 for center, but -1 is close enough

  // none of the analog inputs ever went below 60


  thisHID.get(wheel).min = 60;
  thisHID.get(throttle).min = 60;
  // can set all stick elements at once
  stick.min = 60;

  // ok, now set some ControlSpecs

  thisHID.get(hat).spec = ControlSpec(0, 4, setp:1, default: 0);
  // set all binary buttons at once
  simpleButtons.spec = ControlSpec(0, 1, step: 1, default: 1);

  // all stick elements at once
  stick.spec = ControlSpec(-1, 1, step: 0, default: 0);
  thisHID.get(wheel).spec = ControlSpec(-1, 1, step: 0, default: 0);
  thisHID.get(throttle).spec = ControlSpec(-1, 1, step: 0, default: 0);

  thisHID.action = {arg value, cookie, vendorID, productID, locID, val;

   [value, cookie, vendorID, productID, locID, val].postln;
  };

 });

I wrote all of this yesterday, so this is very demo/pre-release. If something doesn’t work, let me know and I’ll fix it. If people have interest, I’ll post better versions in the future.
